Description
TC35362
Designed for commercial and industrial applications where safety, high performance and continuity of service are essential. Listed to UL standard 98 enclosed and dead front switches. Suitable for use as service equipment when installed in accordance with the National Electrical Code. Suitable for use as transfer equipment in standby systems in accordance with Article 702 of the National Electrical Code. Fusible and non-fusible switches available (consult BuyLog for interrupt ratings). 60/75 C conductor rating. Full cover interlocks. TC35362
Brand:GE
Type:Non-Fused Double Throw
Voltage Rating:600 VAC
Amperage Rating:60 A
HorsePower:10 hp
Phase:3 ph
Frequency Rating:50/60 Hz
Number Of Poles:3
Number of Wires:3
Short Circuit Current Rating:100 kA
Contact Form:TPDT
Actuator Type:Handle
Enclosure Type:NEMA 1
Mounting Type:3-Point/Self-Leveling
Terminal Type:Line/Load Lug
Temperature Rating:60/75 deg C
Dimensions:13 in W x 9.3 in D x 18.8 in H
Material:Steel
Finish:Hot Dipped Galvanized
| Bright red handle is easy to see and easy to grip |
| Highly visible ON/OFF/ON label takes the guesswork out of safety |
| Quick-make quick-break operating mechanism |
| 3-position (ON/OFF/ON) handle is lockable |
| Lockable cover latch meets all safety inspection requirements |
| 60/75 deg C conductor rating |
| Full cover interlocks |
