MS 361
Dynamic 3.4kW-Petrol chainsaw
Outstanding power to weight ratio, state-of-the-art technology and exceptional cutting speed and torque. Fitted standard with STIHL's vibration absorbing RSC chain. Lowest vibrations levels in its class. Available in guide bar sizes 16""/40cm to 20""/50cm.
Technical specifications
Technical specifications |
Value |
Displacement |
59 cm³ |
Power output |
3,4/4,6 kW/bhp |
Weight 1) |
5,6 kg |
Power-to-weight ratio |
1,6 kg/kW |
Sound pressure level 2) |
101 dB(A) |
Sound power level 3) |
114 dB(A) |
Sound power level 3) |
113 dB(A) |
Vibration level left/right 4) |
2,9/3,6 m/s² |
Saw chain pitch |
3/8" |
STIHL Oilomatic saw chain type |
Rapid Super (RS) |
Standard equipment
-
STIHL ElastoStart
Due to compression pressure, jerky stresses occur when starting internal combustion engines. The damping element in the ElastoStart special starter grip alternately absorbs and releases force according to the compression pattern. The result is smooth, even starting.
-
Carburettor heating (V)
By changing the chain saw from summer to winter operation, the intake air is pre-heated over the engine fins. This ensures that the carburettor does not ice up and you can continue working in freezing temperatures.
-
Controlled-delivery oil pump
Different bar lengths, wood types and sawing techniques require different amounts of oil. The controlled-delivery oil pump allows the user to select just the right amount of oil for the job at hand.
-
Side-mounted chain tensioning
Side-mounted chain tensioning makes it easy to tension the chain safely.
-
Advanced combustion technology
Four overflow channels swirl the fuel-air mix before ignition, allowing for optimum combustion and highly efficient performance. The result is lower fuel consumption and high torque across a broad rpm range.
-
Compensator
This controller in the carburettor prevents the fuel-air mixture getting richer as the air filter becomes clogged. The correct quantity of fuel is delivered to the carburettor depending on the quantity of air passing through the air filter. This keeps the fuel/air ratio in the combustion mixture constant and hence also the engine power. The filter doesn't need to be cleaned until an appreciable drop in power occurs.
-
Decompression valve
The decompression valve is part of the easy starting system. The valve should be pressed before starting to reduce the compression pressure when starting, as well as reducing the effort needed to pull the starter rope. The decompression valve is semi-automatic; it must be pressed manually before starting, but then closes automatically.
-
STIHL anti-vibration system
Precisely calculated buffer zones minimise the transfer of engine and saw chain vibrations to the front and rear handles. The chainsaw therefore runs noticeably smoother. This allows the user to save their strength and work longer.
-
STIHL Ematic System
Compared to conventional bars without Ematic, the STIHL Ematic system reduces the consumption of chain lubricant by up to 50 %, depending on the type of wood and the cutting attachment used. This system comprises a STIHL Ematic or Ematic S guide bar, a STIHL Oilomatic saw chain and a variable-flow or reduced-flow oil pump. As a result, virtually every drop of chain lubricant is delivered to exactly the right spot.
-
Single-lever master control
All important functions such as start, choke, throttle and stop are operated via a single lever.
-
Tool free fuel caps
Special caps to open and close the tank cap quickly, easily and without tools.
