18Sound

SPEAKER 18SOUND 6" 6NMB420

(No reviews yet) Write a Review
SKU:
500282000000
MPN:
0adfd74a-1584-11e9-ef2a-d0030fc0c4f2
Shipping:
Calculated at Checkout
On Sale
  • SPEAKER 18SOUND 6" 6NMB420
  • SPEAKER 18SOUND 6" 6NMB420
  • SPEAKER 18SOUND 6" 6NMB420
  • SPEAKER 18SOUND 6" 6NMB420
MSRP: $46,056
Now: $29,936
Was: $46,056
— You save $16,120

Description

Eighteen Sound 6NMB420

Eighteen Sound 6NMB420 is a 6-inch speaker with 44mm voice coil and neodymium magnet. It was created for the reproduction of medium-low frequencies in systems where high intelligibility is required.

Compared to the pure midrange 6ND410 , the Eighteen Sound 6NMB420 has a lower resonance frequency and a higher linear excursion value. Consequently, this speaker shows a higher emission around 250 Hz, with a consequent slightly above 700 Hz output. It is suitable as medium-low in traditional line array or multiway systems, crossover between 200 Hz and 3 kHz; the box could be closed or tuned bass-reflex, with volume starting from 2 liters. The speaker offers superb linearity: the distortion values ​​are minimized by the new design criteria developed by the 18Sound engineers, bringing the 6NMB420 to a very high performance level.

The extremely powerful neodymium magnet ensures a high flow concentration, low Power Compression and excellent heat exchange. The encapsulation of the magnetic structure inside the basket guarantees a constant heat transfer, offering a greater contact space between the back plate and the dissipating structure. In addition, a demodulating ring is used in the construction of this loudspeaker which significantly linearizes the impedance cure ( SDR - Single Demodulating Ring ).

The triple wave suspension design offers effective damping of the moving assembly. In addition, the 44 mm spool is made of light aluminum wire and ensures high linearity and good power handling. Finally, the Eighteen Sound 6NMB420 can be used in humid environments, thanks to the patented water-repellent treatment of the cone.



Features of the 6NMB420
Brand 18Sound
Template 6NMB420
Code 8 Ω: 022068N440 | 16 Ω: 022066N440
Type Medium low
Power (W AES ) 200
Nominal impedance (Ω) 8-16
Sensitivity (dB SPL 1W / 1m) 100
Diameter (mm / in) 152/6
Coil Diameter (mm) 44
Weight kg) 1.25
Technologies SDR (Single Demodulating Ring)
