SPEAKER 18SOUND 18" 18NLW9601
- SKU:
- ALT189601WF08NA
- MPN:
- 0adfd74a-1584-11e9-ef2a-d00300dc6b2b
- Shipping:
- Calculated at Checkout
On Sale
Description
The 18NLW9601 is an extended low frequency 18 inch neodymium high performance transducer. It is the evolution of the industry standard 18NLW9600. The loudspeaker has been designed for use as a subwoofer component, in either a reflex, bandpass or horn loaded high SPL demanding applications. For optimum results recommended amplifier should be able to deliver 3600 Watt program power. At the heart of teh transducer stands a double silicon spider based on DSS technology let the 18NLW9601 being able to control the moving mass with high linearity, showing an exceptional stability of mechanical parameter values in the long term. The state-of-the-art 5,3" diameter ISV copper clad aluminum wire CCAW voice coil shows a inside-outside split winding, four layers design, enabling the 18NLW9601 to handle up to 3600W program power. Bl force factor, as well as all other electro-dynamic parameters, are linear within the working range. This, together with the exceptional high excursion behavior - 70mm before damage, ±14mm linear Xmax - makes the 18NLW9601 an extremely low distortion, highly dynamic transducer. The already low distortion and sound quality have been further improved by the aluminum demodulating ring (SDR technology), that flatten impedance and phase versus frequency. The 18NLW9601 has been developed after intense FEA and fluidodynamics simulation and testing, focusing on dissipating the heat generated by the powerful voice coil. Special attention was given to the optimization of air flow into the gap without introducing audible noise. A low-density foam diffractor placed into the vent hole acts as a cooling system, increasing the power handling capability and lowering the power compression figure. The carbon fiber reinforced, straight ribbed cone shows a proprietary resin treatment for extra pulp strength and water repellent properties. A special coating applied to both the top and back plates makes the transducer far more resistant to the corrosive effects of salts and oxidization.
Extended Speaker
- 18" Neodymium chassis
- Power: 1800 Watt AES
- Impedance: 8 Ohm
- Sensitivity: 97 dB SPL 1W/1M
- Frequency range: 32 Hz - 2.5 kHz
- XMax 14 mm
- Qts 0.28
- Fs 34 Hz
- Weight: 12.8 kg
Further Information
Impedance | 8 Ohms |
---|---|
Load Capacity | 1800 W |
Resonant frequency | fS | 39 | Hz |
Electrical Q | QES | 0.30 | |
Mechanical Q | QMS | 5.70 | |
Total Q factor | QTS | 0.28 | |
Suspension equivalent air volume | VAS | 120 | litres |
DC resistance | RE | 4.7 | Ω |
Minimum impedance | Zmin | 6.1 | Ω |
Voice coil inductance | LE | 2.19 | mH |
Force factor | B·l | 31 | T·m |
Suspension mechanical resistance | RMS | 11 | N·s/m |
Suspension mechanical compliance | CMS | 66 | µm/N |
Moving mass | MMD | 227.7 | g |
Moving mass (including airload) | MMS | 255 | g |
Surface of the diaphragm | SD | 1130 | cm² |
Effective diaphragm diameter | Ø | 37.9 | cm |
Maximum linear excursion | Xmax | ± 14 | mm |
Excursion limit | Xlim | ± 35 | mm |
Displacement volume at Xmax | VD | 1582 | cm³ |
Efficiency | η₀ | 2.32 | % |
Efficiency bandwidth product | EBP | 130 |
Overall diameter | 462 | mm |
Baffle hole diameter | 422 | mm |
Overall depth | 236 | mm |
Flange thickness | 26 | mm |
Net weight | 12.8 | kg |
Diaphragm material | Straight ribbed carbon fiber loaded cellulose | |
Surround material | Triple Roll, Heavy Polycotton | |
Voice coil diameter | 135 | mm |
Coil material | Aluminum | |
Magnet | Neodymium |
