A refrigerator that blends beautifully into
the kitchen.

Even more features

From helpful notifications to Triple Cooling, there's more to love
in the new AI Family Hub™+.

• Get useful notifications

  With Wi-Fi-enabled capabilities, SmartThings will alert you when the door is left open, if there is an unexpected change in temperature, or when it's time to change the water filter.

• Helps you use up to 10% less household energy⁴

  SmartThings AI Energy Mode⁴ helps you reduce your energy consumption, saving you money.

• Keep your fridge fresh every day

  Keep the air in your fridge fresh day after day with a built-in deodorizing filter.

• Powerful cooling performance

  Precise temperature and humidity controls in all three zones to help your food stay fresher for longer.

ENERGY STAR^® certified⁵

Retains cold air in
the fridge

Retains cold air in the fridge, even while your fridge door is open.

Measure for a perfect fit

Bespoke 4-Door Flex™ Refrigerators have unique height and depth dimensions. Measure your installation clearances and view specifications to ensure it will fit your space.



Family Hub™+
Family Hub™+
Yes
Auto Open Door
Beverage Center™
Beverage Center™
Dual Auto Ice Maker
Dual Auto Ice Maker
FlexZone™
FlexZone™
ENERGY STAR® Certified
ENERGY STAR® Certified
Hide All Specs
Key Features
 Download Spec Sheet
BESPOKE

Yes

Space Max Technology™

Yes

Family Hub™

Yes

Metal Cooling

Yes

Ice Maker

Yes

Dual Ice Maker

Yes

Beverage Center™

Yes

FlexZone™

Yes

Internal Camera

Yes

Wi-Fi Connectivity

Yes

Ice/Water Dispenser

Water Only

ENERGY STAR® Certified

Yes

Auto Open Door

Yes

AI Family Hub™+

Yes

AI Vision Inside

Yes

Bespoke AI

Yes

FamilyHub+

Yes

Standard Features
Additional Filtered Ice Maker In the Freezer

Yes - dual ice maker in freezer

High-Efficiency LED Lighting

Yes

AI Home

Triple Cooling

Surround Air Flow

Yes

Power Freeze and Power Cool Options

Yes

Humidity Controlled Crispers

Yes

Shelves

Yes

Gallon Bins

Yes

Stainless Steel Interior Accents

Yes

2-Minute Door Alarm

Yes

Beverage Station

Yes

CoolTight Door

Yes

Display Color

Cool White

Filter Indicator

Yes

Handles

Recessed

Water Filter

HAF-QIN/EXP

Multi Air Flow

Yes

Refrigerant

R600a

Speaker

Yes

Wi-Fi Connectivity

Yes

Adjustable Shelves

Yes

Modern Look Design

Yes

Built in Look w/Counter Depth

Yes

High-Efficiency LED Lighting

Yes

Tempered Glass Spill Proof Shelves

Yes

Flat Doors w/ Smooth Finish

Yes

Temperature Range

Fridge : 34℉ ~ 44℉ Freezer : -8℉ ~ 5℉

Refrigerator Design
General Feature

4-Door Flex

Color

Stainless Steel

Free Standing

Yes

Number of Doors

4

Depth

28 3/4"

Refrigerator Features
AutoFill Water Pitcher

Yes

Gallon Bins

2

Gallon Door Bins

Yes

Total Bins

6

Fixed Shelves

Yes

Foldable Slide-in Shelf

Yes

Interior Light

HE LED

Internal Digital Display

Yes

Internal Filtered Water Dispenser

Yes

Plastic Shelves

No - tempered glass

Shelves

4

Slide-In Shelf

Yes

Spill proof shelves

Yes

Temperature Sensors

Yes

Water and Ice Dispenser

Water Only

Automatic Ice Maker

Yes

Showcase Door

Yes

FlexZone™

Yes

FlexZone™
Total Capacity (cu. ft.)

4.4

Shelf

2

Drawers

1

Temperature Zones

-8F - 5F (Freeze) 23F (Soft Freeze) 30F (Meat / Fish) 25F (Fruits / Veggies) 39F (Chill)

Freezer Features
Total Ice Storage

6.8 lbs/day

Built-In Automatic Icemaker

Yes

Cubed and Crushed Ice

Cubed Ice and Ice Bites

Icemaker

Yes

Interior Light

Yes

Shelves

1

Door Bins

3

Freezer Box

1

Family Hub Features
Window Size

32"

Window Material

Glass

Display Size

32"

Display Resolution

Full HD (1080x1920)

Display Touch Type

Capacitive touch

Processor

1.8GHz Hexa

RAM

DDR 3GB

Flash Memory

eMMC 16GB

Connectivity

Wi-Fi & Bluetooth

Operating System

Tizen

Speaker

Yes

Mic

Yes

Camera

Yes

USB Port

Yes

Energy Usage
CEE Rating

E-Star

Power
Energy Consumption

631 kWh/yr

Volt/Amps

115V / 60 Hz

Capacity
Total Capacity (cu. ft.)

22.8

Refrigerator Capacity (cu. ft.)

14

Freezer Capacity (cu. ft.)

8.8

Ice making capacity

5.1 lbs / day

Dimensions
Fridge-Side Convertible Compartment Capacity

5.8

Product Dimensions with Hinges, Handles and Door

35.875" (W) x 73" (H) x 28.75" (D)

Product Dimensions without Hinges and Door

35.875" (W) x 70.75" (H) x 24" (D)

Product Dimensions with Door with Handles

35.875" (W) x 73" (H) x 28.75" (D)

Product Dimensions with Door without Handles

35.875" (W) x 73" (H) x 28.75" (D)

Product Dimensions with Doors Open

35.875" (W) x 73" (H) x 43" (D)

Product Dimensions without Hinges or Handles

35.875" (W) x 70.75" (H) x 28.75" (D)

Product Dimensions without Door without Handles

35.875" (W) x 70.75" (H) x 24" (D)

Shipping Dimensions

38.25" (W) x 78.625" (H) x 30 5/8" (D)

Net Depth with Door Handle

28.75"

Net Height with Hinge

73"

Net Height without Hinge

70.75"

Net Depth w/o Door Handle

28.75"

Depth without Door (in)

24"

Width

35 7/8"

Height

73"

Weight
Product Weight (lbs.)

341.7

Shipping Weight (lbs.)

361.6
