Description
General Features
- STAX 4-Channel Class A/B Car Amplifier
- RMS Power Rating:
- 4 ohm: 150 watts x 4 chan.
- 2 ohm: 180 watts x 4 chan.
- Bridged, 4 ohm: 360 watts x 2 chan.
- Max power output: 1600 watts
- MOSFET power supply
- LED power and protect indicators
- Bass Boost/EQ details (0-12 dB bass boost at 45 Hz)
- 4/3/2 channel operation
- 3-Way System Protection circuitry (thermal, overload, and speaker short protection)
- Heavy duty aluminum alloy heatsink for maximum heat dissipation
- Silver-plated RCA level inputs
- Silver-plated screw terminals
- Variable high-pass filter (50-500 Hz, 24 dB/octave)
- Variable low-pass filter (30-250 Hz, 24 dB/octave)
- Frequency response: 10-30,000 Hz
- Dimensions: 14-3/4"LÂ x 9-5/8"WÂ x 2-1/8"H
Power Specifications - Full Range Channels
RMS Power @ 4 ohms
150Â watts x 4Â channel
RMS Power @ 2 ohms
180Â watts x 4Â channel
RMS Power @ 1 ohm
Not Stable
Bridged RMS Power
360Â watts x 2Â channel
Amplifier Specifications
Amplifier Class
A/B
Number of Channels
4-Channel
Total Peak Power Output
1600Â watts
Total RMS Power Output
720Â watts
Maximum Input Gauge Size
4Â AWG
Minimum Impedance Unbridged
2Â ohm
Minimum Impedance Bridged
4 ohms
THD at Rated RMS Power
0.02%
Speaker Level Inputs
No
Preamp Outputs
1 pair
Built-in Crossover
Low-Pass (LP)
High-Pass (HP)
Full (AP)
High-Pass (HP)
Full (AP)
High-Pass Crossover Frequency
50 - 500Â Hz
Low-Pass Crossover Frequency
30 - 250Â Hz
Signal-to-Noise Ratio
97Â dB
Bass Boost
0 - 12Â dB
Remote bass/level controller
No
Fuse Rating
25A x 2Â
